Finish: Self, Black, Bright Zinc, Hot Dip Galvanized
| Size | "d1" Min | "d1" Max | "dc" Max | "dc" Min | "h" Nominal | "h" Max | "h" Min | With per 1000pcs in kgs |
|---|---|---|---|---|---|---|---|---|
| M2.5 | 2.7 | 2.84 | 8 | 7.64 | 0.8 | 0.9 | 0.7 | 0.28 |
| M3 | 3.2 | 3.38 | 9 | 8.64 | 0.8 | 0.9 | 0.7 | 0.349 |
| M3.5 | 3.7 | 3.88 | 11 | 10.6 | 0.8 | 0.9 | 0.7 | 0.529 |
| M4 | 4.3 | 4.48 | 12 | 11.6 | 1 | 1.1 | 0.9 | 0.774 |
| M5 | 5.3 | 5.48 | 15 | 14.6 | 1.2 | 1.4 | 1 | 1.46 |
| M6 | 6.4 | 6.62 | 18 | 17.6 | 1.6 | 1.8 | 1.4 | 2.79 |
| M7 | 7.4 | 7.62 | 22 | 21.5 | 2 | 2.2 | 1.8 | 5.29 |
| M8 | 8.4 | 8.62 | 24 | 23.5 | 2 | 2.2 | 1.8 | 6.23 |
| M10 | 10.5 | 10.77 | 30 | 29.5 | 2.5 | 2.7 | 2.3 | 12.2 |
| M12 | 13 | 13.27 | 37 | 36.4 | 3 | 3.3 | 2.7 | 22.2 |
| M14 | 15 | 15.27 | 44 | 43.4 | 3 | 3.3 | 2.7 | 31.6 |
| M16 | 17 | 17.27 | 50 | 49.4 | 3 | 3.3 | 2.7 | 40.9 |
| M18 | 20 | 20.52 | 56 | 54.1 | 4 | 4.6 | 3.4 | 67.4 |
| M20 | 22 | 22.52 | 60 | 58.1 | 4 | 4.6 | 3.4 | 76.8 |
| M24 | 26 | 26.84 | 72 | 70.1 | 5 | 6 | 4 | 139 |
| M30 | 33 | 34 | 92 | 89.8 | 6 | 7 | 5 | 273 |
| M36 | 39 | 40 | 110 | 108 | 8 | 9.2 | 6.8 | 522 |
All data for information purpose only. For more details on product standards or dimensions, please feel free to contact us at centuryboltcentre@gmail.com
